| 品牌： | 佳洁 |
| 型号： | 156POLT |
| 类型： | 多晶硅 |
| 转换效率： | 18 % |
| 输出功率： | 4.3 W |
| 品质等级： | A级 |
| 产品认证： | CE |
佳洁牌156多晶电池片
佳洁牌156多晶电池片
Table Table 3. Electrical parameters for polycrystalline cells of size 156 x 156 mm2
TPB156 | 转换效率 | ***大功率 | ***大功率点电压 | ***大功率点电流 | 开路电压 | 短路电流 |
TPB156180 | 18.00 | 4.407 | ～0.540 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156177 | 17.75 | 4.346 | ～0.536 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156175 | 17.50 | 4.284 | ～0.532 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156172 | 17.25 | 4.223 | ～0.528 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156170 | 17.00 | 4.162 | ～0.525 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156167 | 16.75 | 4.101 | ～0.520 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156165 | 16.50 | 4.040 | ～0.516 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156162 | 16.25 | 3.978 | ～0.512 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156160 | 16.00 | 3.917 | ～0.508 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156157 | 15.75 | 3.856 | ～0.505 | ～7.683 | 0.615±5% | 8.273±5% |
TPB156155 | 15.50 | 3.770 | ～0.497 | ～7.581 | 0.611±5% | 8.174±5% |
TPB156152 | 15.25 | 3.710 | ～0.494 | ～7.519 | 0.608±5% | 8.116±5% |
TPB156150 | 15.00 | 3.651 | ～0.491 | ～7.438 | 0.606±5% | 8.043±5% |
TPB156147 | 14.75 | 3.591 | ～0.488 | ～7.364 | 0.604±5% | 8.000±5% |
TPB156145 | 14.50 | 3.529 | ～0.487 | ～7.242 | 0.603±5% | 7.858±5% |
TPB156142 | 14.25 | 3.469 | ～0.485 | ～7.158 | 0.602±5% | 7.791±5% |
TPB156140 | 14.00 | 3.409 | ～0.482 | ～7.072 | 0.600±5% | 7.727±5% |
TPB156137 | 13.75 | 3.348 | ～0.480 | ～6.974 | 0.598±5% | 7.639±5% |
TPB156135 | 13.50 | 3.287 | ～0.478 | ～6.881 | 0.596±5% | 7.565±5% |
TPB156132 | 13.25 | 3.227 | ～0.476 | ～6.779 | 0.595±5% | 7.501±5% |
TPB156130 | 13.00 | 3.165 | ～0.474 | ～6.683 | 0.594±5% | 7.457±5% |
TPB156127 | 12.75 | 3.104 | ～0.472 | ～6.583 | 0.593±5% | 7.426±5% |
TPB156120 | 12.00 | 2.873 | ～0.466 | ～6.171 | 0.591±5% | 7.385±5% |
注：测试条件为100mW/cm2，AM1.5，25℃ | ||||||
