| 参考重量 | 0.9Kg |
|---|---|
| 工作电流 | 0.56 |
| 工作电压 | 18v |
| 开路电压 | 21.6V |
| 类型 | 层压太阳能电池板/组件 |
| 外形尺寸 | 340*250*17mm |
| 用途 | 太阳能发电 |
| 原理 | 光—电转换方式 |
| 转化效率 | 0.18 |
| 最大功率 | 10w |
| 型号 | XN-18V10W-P |
| 加工定制 | 是 |
| 使用状态 | 平板太阳电池 |
| 化学类型 | 多晶硅太阳电池 |
| 系统电压 | 12V |
| 质量认证 | CE |
| XN-18V10W-P | |||||
| Maximum power (Wp) **大功率 | 10w | ||||
| Maximum power voltage (V) 工作电压 | 18v | ||||
| Maximum power current (A) 工作电流 | 0.55A | ||||
| Open circuit voltage (V) 开路电压 | 21.5v | ||||
| Short circuit current (A) 短路电流 | 0.61A | ||||
| Number of cells (Pcs) 电池片数量 | 36 | ||||
| Size of module (mm) 电池板尺寸 | 340*250*17mm | ||||
| | | ||||
| Weight per piece (kg) 电池板重量 | ≈0.9kg | ||||
| Junction Box Type 接线盒 | PPO, black | ||||
| | | | | ||
| | | | | ||
| Cell Size(mm)硅片规格 | 156*156 | ||||
| Cell Efficiency (%) 转换效率 | ≥18.4% | ||||
| frame (Material, Corners, etc.) 框架材料 | Anodized Aluminum Alloy铝合金 | ||||
| Standard Test Conditions测试标准参数 | AM1.5 100MW/c㎡ 25℃ | ||||
| Warranty 产品保证 | 5 years for the whole product, for the power, 90% within the first decade, 80% for the next decade. | ||||
| FF (%) 电池板填充率 | ≥73.3% | ||||
